Welcome to our Starter search

Let us guide you through your search to find the suitable construction for your design.
This is how our straightforward Starter search works:

1. Answer questions
2. Select a suitable construction
3. Check the system layer PDF & properties
4. Login to myEGGER: Download construction data without restrictions

Our tip: Simply highlight your favorites to stay informed of any updates!

Technical Support

You have any technical questions or need support concerning our products and their application? Our application engineers are pleased to support you with any queries you have:



You can find more information on the topic at Basics of timber construction

For which component do you need a solution?

Please enter your mounting situation:

Note: Room-sealing walls are only exposed to fire on onse side (standard). They usually serve to prevent fire transmission between different fire compartments.

Room closure

(27)

Load-bearing effect

(31)
(3)

Please select the desired application area:

Application area

(1)
(5)

What fire protection requirements do you have to fulfill?

 Note: The higher the fire protection requirement, the more layers of material are needed to achieve the protection goal.

Fire protection

(3)
(3)
(3)
(3)

What sound insulation requirements do you have to meet?

Sound insulation

(5)
(21)
(8)

Which type of insulation will you use?

 Note: Natural insulation materials may mean that certain fire resistance durations cannot be achieved.

Insulation

(10)
(8)
(20)
(10)
34 matched constructions

All constructions

Partition wall

Construction E1201-02

E1201-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI30 / REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/10-BB
  • Application: Building end wall, OSB on the inside
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1202-02

E1202-02
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI30 / REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/21-BB
  • Application: Building end wall on the inside with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Variable insulation material possible
Partition wall

Construction E1203-03

E1203-03
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: F30-B / F90-B
  • Application: Building end wall, OSB on the inside
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1210-02

E1210-02
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/24-BB
  • Application: Building partition wall with gypsum fire board- or gypsum fibre board cladding
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1211-02

E1211-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI45
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/22-BB
  • Application: Building partition wall with gypsum fire board- or gypsum fibre board cladding
  • Heat insulation: Variable insulation material possible
Partition wall

Construction E1213-02

E1213-02
Construction layer (PDF)
File size 1,5 MB
  • Fire resistance: REI60
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/23-BB
  • Application: Building partition wall with gypsum fire board- or gypsum fibre board cladding
  • Heat insulation: Variable insulation material possible
Partition wall

Construction E1214-02

E1214-02
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/24-BB
  • Application: Building partition wall with gypsum fire board- or gypsum fibre board cladding
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1215-02a

E1215-02a
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/10-BB
  • Application: Building partition wall witht gypsum fire board cladding
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1301-02

E1301-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI60
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/09-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1302-01

E1302-01
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: EI0
  • Application: Non-load-bearing partition wall with timber framework
  • Heat insulation: Insulation material B2
Partition wall

Construction E1302-01a

E1302-01a
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: EI0
  • Application: Non-load-bearing partition wall with timber framework
  • Heat insulation: Insulation material B2
Partition wall

Construction E1302-02

E1302-02
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/24-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1303-01

E1303-01
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: EI0
  • Application: Non-load-bearing partition wall with timber framework
  • Heat insulation: Insulation material B2
Partition wall

Construction E1303-02

E1303-02
Construction layer (PDF)
File size 1,4 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/10 + 17-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1303-02a

E1303-02a
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/10 + 17-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1306-02a

E1306-02a
Construction layer (PDF)
File size 1,5 MB
  • Fire resistance: REI30
  • Fire classification report: Classification report HF Austria 2586/2018/20-BB
  • Application: Load-bearing, room-enclosing partition wall with single-layer cladding
  • Heat insulation: Variable insulation material possible
Partition wall

Construction E1306-03

E1306-03
Construction layer (PDF)
File size 1,5 MB
  • Fire resistance: F30-B
  • Fire classification report: abP MFPA P-SAC-02/III-752
  • Application: Load-bearing, room-enclosing partition wall with single-layer cladding
  • Heat insulation: Cellulose insulation
Partition wall

Construction E1306-03a

E1306-03a
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: F30-B
  • Fire classification report: abP MFPA P-SAC-02/III-752
  • Application: Load-bearing, room-enclosing partition wall with single-layer cladding
  • Heat insulation: Cellulose insulation
Partition wall

Construction E1307-02

E1307-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI30
  • Fire classification report: Classification report HF Austria 2586/2018/23-BB
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: Variable insulation material possible
Partition wall

Construction E1307-02a

E1307-02a
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI30
  • Fire classification report: Classification report HF Austria 2586/2018/23-BB
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: 120 mm variable insulation material possible
Partition wall

Construction E1308-02

E1308-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI45
  • Fire classification report: Classification report HF Austria 2586/2018/22-BB
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: 100 mm variable insulation material possible
Partition wall

Construction E1308-02a

E1308-02a
Construction layer (PDF)
File size 1,3 MB
  • Fire resistance: REI45
  • Fire classification report: Classification report HF Austria 2586/2018/22-BB
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: 120 mm variable insulation material possible
Partition wall

Construction E1310-03

E1310-03
Construction layer (PDF)
File size 1,1 MB
  • Fire resistance: F30-B
  • Application: Load-bearing, room-enclosing partition wall with single-layer cladding
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1312-03

E1312-03
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F60-B
  • Application: Load-bearing, room-enclosing partition wall with Plasterboard cladding
  • Heat insulation: Rock wool 50 kg/m³
Partition wall

Construction E1312-03a

E1312-03a
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F60-B
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: Rock wool 50 kg/m³
Partition wall

Construction E1314-03

E1314-03
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F60-B
  • Application:Load-bearing, not room-enclosing partition wall with Plasterboard cladding
  • Heat insulation: Insulation material B2
Partition wall

Construction E1314-03a

E1314-03a
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F60-B
  • Application:Load-bearing, not room-enclosing partition wall with Plasterboard cladding
  • Heat insulation: Insulation material B2
Partition wall

Construction E1315-03

E1315-03
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F30-B
  • Application: Load-bearing, not room-enclosing partition wall with single-layer cladding
  • Heat insulation: Insulation material B2
Partition wall

Construction E1315-03a

E1315-03a
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: F30-B
  • Application: Load-bearing, not room-enclosing partition wall with single-layer cladding
  • Heat insulation: Insulation material B2
Partition wall

Construction E1316-02

E1316-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI60
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/09-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Glas wool 11 kg/m³
Partition wall

Construction E1317-02

E1317-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/24-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
Partition wall

Construction E1318-02

E1318-02
Construction layer (PDF)
File size 1,2 MB
  • Fire resistance: REI90
  • Verwendbarkeitsnachweis Feuer: Klassifizierungsbericht HF Austria 2586/2018/24-BB
  • Application: Load-bearing, room-enclosing partition wall with gypsum fire board or gypsum fibre board cladding
  • Heat insulation: Rock wool 30 kg/m³
Partition wall

Construction E1319-03

E1319-03
Construction layer (PDF)
File size 1,1 MB
  • Fire resistance: F90-B
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: Rock wool 50kg/m³
Partition wall

Construction E1319-03a

E1319-03a
Construction layer (PDF)
File size 1,1 MB
  • Fire resistance: F90-B
  • Load-bearing, room-enclosing partition wall with gypsum fire board cladding
  • Heat insulation: Rock wool 100kg/m³
